HDTV Universal Test Chart
The YE0117 is designed for the quick (mainly visual) appraisal of HDTV cameras transmission characteristics....
Sector Star Test Chart (36 cycles)
The YE0120 test chart is designed for the adjustment of camera lenses and checking back focal distance. It shows a 36 sector Siemens star on a white background. ...
Sector Star Test Chart (72 cycles)
The YE0121 test chart is designed for the adjustment of camera lenses and checking back focal distance. It shows a 72 sector Siemens star on a white background. ...
White Balancing Test Chart
The test chart consists of a blank film between two glass panes. The test chart is designed for shading measurement under the same lightning conditions as other transparency measurements. ...
Streaking Measurement Test Chart
The YE0175 is designed for measurement of the disturbance caused by the video level in black areas to the right of or below the areas. Horizontal white lines are positioned on a black background. Definition of streaking measurements Measure...
Bar Test Chart(IEC 61146)
The bar test chart is designed for checking the transmission characteristics of TV cameras at intermediate and deep frequencies....
